No.1.5 Hippo Hammer Mill

Description

All Hippo hammer mills from models Baby up to Size 69 are based on cast iron milling plates, which drastically increases the lifespan of the mill, compared to any other mill in the world.







The Hippo size 1 ½ is the mill secondly developed by Arthur Collins in the range of cast iron hammer mills for mainly small industrial and farm use, with higher capacity than the size 1 mill and its main distinctive feature its wide intake – 50% wider than the size 1 mill. It otherwise has the same high quality parts as all Hippo mills. All milling tips are manufactured from Bennox steel to ensure long lifetime on these parts. Optionally Hardox or other milling tips may be substituted for special applications. Hippo size 1 ½ is a powerful mill, with capacity is not the main issue.




Data on No. 1.5 Hippo Hammer Mill

Power required: 11KW 3 Phase 380V Electric / 16HP Diesel / PTO
Capacity: 0.8mm Screen 350kg/hr
1.6mm Screen 750kg/hr
8mm Screen 1850kg/hr
Capacity is based on dry maize
Length: 3,254mm
Width: 1,341mm
Height: 2,361mm
Net weight: 255kg
Rotor diameter: 315mm
Number of beaters: 8
Number of tips: 32
Tip Speed: 74m/s
RPM: 4500RPM
Hippo Mills Instruction manual



Chili
Chili
Clove
Clove
Coriander
Coriander
Maize
Maize
Pepper
Pepper
Turmeric
Turmeric
Dry Barley
Dry Barley
Wet Barley
Wet Barley
Oats
Oats
Rice
Rice
Hay
Hay
